- Horizontal end milling machine with manual feed to machine the ends of aluminium or PVC profiles
- use of milling disks, cutter blocks or special shaped disks, max. Ø 300 mm
- Pneumatic feed of cutter disk, hydraulic controlled
- Motor 2,2 KW, 400 V, 50 Hz
- Pneumatic material clamping horizontal and vertical
- Material stop adjustable 20° – 90° – 20° with scale
- Tool quick change device
- Notching width max. 400 mm
- Notching depth max. 110 mm
- Profile height max. 190 mm
Options:
- Electronic digital display for material stop
- Depth stop adjustable by hand wheel – read out with mechanical display
- Cutting disks infinitely adjustable in height by hand wheel – read out by scale
