• For cutting to length and punching aluminum profiles.
• Fully automatic operation with graphic controls.
• Drive 7,5 kW, S6, 400 V, 50 Hz, 2850 rpm.
• For use of saw blades Ø 500 or 550 mm.

• Siemens S7 control with touch display incl. piece counter
• incl. reversing device up to a cut-off length max. 1,5 m
• Re-gripping from material feed after sawing or during the sawing process
• Regripping from material feed – entire area (800 mm) or short area

• Motorized saw blade feed, infinitely variable, from bottom to top
• Vertical and horizontal clamping device, on the infeed and outfeed side of the saw head
• Cutting gap extension on both sides of the saw blade
• Electronic material feed unit with ball screw and servo motor, including pneumatic horizontal and vertical clamping device,
• The profile support area in the area of the feed is equipped with a lifting/lowering roller
• Rest piece from 75 mm
• Clamping pressure reduction horizontal and vertical
• Cycle testing device with level monitoring and automatic shut-off,
• Noise protection package

• On the section side there is a hydraulic punching device, drive hydraulic, incl. oil cooler.
• One cylinder vertically from the top, punching stroke max. 20 mm, adjustable downwards via a knurled screw
• One punching cylinder horizontally from the front, punching stroke 20 mm
• Punching force 150 KN per cylinder
• Cylinders can be selected / deselected via the control system
